The “Smart Choice” for laboratory equipment
PRODUCT INFO
Performance and Features
- Cold rolled plate with powder coated painting to ensure anti-corrosion and durability
- SS304 inner chamber for easy clean.
- Adjustable and removable stainless steel shelves easy for setting different samples and clean the chamber
- With 126mm thick polyurethane foam insulation to minimize temperature lose
- Independent inner doors to minimize cold air leakage
- Magnetic door seal to ensure optimal sealing of door to fridge
- Castors wheels for easy relocation when needed
- Touch screen for easy operation, user rights setting to ensure safety of sample
Safety & Peace of Mind
- Auto Start Feature after power loss/return
- High condenser temperature alarm
- Power failure alarm
- Temperature sensor failure alarm
- Low battery alarm
- High / Low temperature alarm
- Door open alarm
Options
-
Racks & boxes
Chamber Volume Racks Boxes 390L 5*3 Racks 16 pieces 9*9 Boxes( for 2ml tubes) 240 pieces 490L 5*4 Racks 16 pieces 9*9 Boxes( for 2ml tubes) 320 pieces 650L 5*4 Racks 20 pieces 9*9 Boxes( for 2ml tubes) 400 pieces
-
Extra interior chamber temperature probe
-
LN2/CO2 backup system
Easy temperatures set to start or stop backup system.
Manual and Auto models available
-
Chart recorder
≥7 days’data can be stored.
-
Voltage stabilizer
Power input 160V - 250V Power output 220V ∽ ±4% Over voltage 246V ±4V Action ≤6S
|
Usable Volume |
390 Liters |
|
Temperature Range |
-50 ～ -86℃ |
|
Temperature Uniformity |
≤ 6℃ |
|
Minimal temperature |
-86 |
|
Cooling time |
≤ 8 h |
|
Exterior dimensions（W x D x H） |
909 x 797 x 1990mm |
|
Interior dimensions (W x D x H） |
589 x 505 x 1310mm |
|
Door opening W x H |
589 x 1310mm |
|
Insulation thickness |
126mm |
|
Exterior finishing |
White plastic coated galvanised steel |
|
Interior finishing |
Stainless steel |
|
Inner door |
4 |
|
Shelves |
3 |
|
Mechanical lock |
Yes |
|
Data logger |
Yes |
|
Battery |
Yes |
|
Interior chamber temperature probe |
Yes |
|
Vent port |
Yes |
|
Gasket heating |
Yes |
|
Refrigerant type |
Non HCFC |
|
Weight |
283Kg |
|
Power |
1300W |
No.
Yes.
BEING puts a product identification label above the power cord.
Yes.
Yes. We would need the unit's model and serial numbers if the certificate didn't come with your BEING instrument.
| Packaging Materials | Wooden Crate |
|---|---|
| Outside Dimensions (in./mm) | |
| 43.3 x 41.7 x 86 | |
| 1100 x 1060 x 2180 | |
| Shipping Weight (lbs./kg) | |
| 710.6 | |
| 323.0 | |
| Freight Class | 0.0 |
